规格 & 性能(Specifications & Performance) | |
载流量(Current-carrying) | 200A Max. |
接线方式(Connection mode) | 超声波焊接&B 型压接 |
适配线径(Fit for wire diameter) | 35 & 50 & 70m㎡ |
工作温度(Operating temperature) | -40~125℃ |
接触电阻(Contact resistance) | ≤0.3mΩ |
插拔寿命(Durability) | ≥500 mating cycles |
材质(Material) | 插套：紫铜(Socket:Copper) |
簧片：高性能铜合金 | |
镀层(Plating) | 银(Silver) |
适配插针(Adapter pin) | T=1.80±0.03 |
产品选型表（Product selection table) | |
料号(P/N) | 接线方式(Connection mode) |
NSQ200-001 | B形压接35m㎡线缆 |
NSQ200-002 | B形压接50m㎡线缆 |
NSQ200-003 | 超声波焊接35 & 50 &70m㎡线缆 |
